#Kmia runway 27 localizer frequency fsx pdf
Instrument Procedures NOTE: All procedures below are presented as PDF files. PPR FOR ACFT WITH WINGSPAN GTR THAN 171 FT & TAIL HGT GTR THAN 60 FT ON TWY N BTWN TWY Q & TWY T6īIRDS ON & INVOF ARPT CONCENTRATION OF BIRDS BLW 500 FT 2.0 NM W OF 10L & 10R AER. PREFERENTIAL RWY USE PROGRAM IN EFCT CTC NOISE ABATEMENT OFFICE. DUE TO ELEV ALL ACFT REMAIN ON CNTRLN TWY T8 & TAXILANE T NOT ACCESSIBLE FM TWY J.ĪCFT LDG RWY 10R & EXITING J9 FOLLOW TWY LEAD OFF LINE ONTO J9. TURB BLW 1000 FT OVR LANDFILL LCTD 2 NM W.ĪLL RWYS NOISE SENSITIVE NOISE ABATEMENT IN EFCT - 95.
RAMP CTL EFF - CTC ARPT OPS FOR HRS.ĪSDE-X IN USE OPR PARROT WITH ALT RPRTG MODE & ADS-B (IF EQUIPPED) ENABLED ON ARPT SFCS. IR CARRIER ACFT USE RAMP PUSH BACK PROCS PRESCRIBED BY ARPT OPS.ĮAST SIDE OF CONCOURSE B AVBL TO ACFT WITH WINGSPAN LESS THAN 124.9 FT.ĪCFT OPRG FROM TRML 1, 2, 3, 4 MUST CTC RAMP CTL. TWY A BTN TWY A2 & TWY A3 CLSD TO ACFT WINGSPAN MORE THAN 170 FT & TAIL HGT MORE THAN 59 FT EXC 10 MIN PPR 95. TWY B EAST OF TWY B12 & TAXILANE T EAST OF TWY T1 CLSD TO ACFT WITH WINGSPAN GTR THAN 118 FT & TAIL HGT GTR THAN 45 FT. NO VFR APCHS OR BASE LEGS UNTIL OFFSHORE. TWY E BTN TWY C & TWY L CLSD TO ACFT WINGSPAN MORE THAN 118 FT EXC 10 MIN PPR 95.ĪRR FM N & W MNTN 6000 FT UNTIL ABM RWY 28R ON DOWNWIND ARR FM N MNTN 6000 FT UNTIL ABM RWY 10L ON DOWNWIND. * for 12-month period ending 31 December 2022ĪRSTG GEAR/SYS: ENGRD MTRLS ARSTG SYS (EMAS) 562.9 FT IN LEN BY 178.2 FT IN WID AT THE DEP END OF RWY 28L.ĪRSTG GEAR/SYS: ENGRD MTRLS ARSTG SYS (EMAS) 562.9 FT IN LEN BY 178.2 FT IN WID AT THE DEP END OF RWY 10R.ĪRSTG GEAR/SYS: ENGRD MTRLS ARSTG SYS (EMAS) 251 FT IN LEN BY 170 FT IN WID AT THE DEP END OF RWY 28R.ĪRSTG GEAR/SYS: ENGRD MTRLS ARSTG SYS (EMAS) 409 FT IN LEN BY 170 FT IN WID AT THE DEP END OF RWY 10L.ĬLSD TO ACR TRAINING LRG ACFT TRNG OVER 58000 LBS MAX CERTD GROSS TKOF WEIGHT ALL TRNG 2300-0700. left of centerline, 18:1 slope to clearĪirport Ownership and Management from official FAA records Ownership:Īirport Operational Statistics Aircraft based on the field: RWY 10R MALSF NSTD 370 FT GAP BTN 8+00 & STATION 11+70.ģ5 ft. MALSF: 1,400 foot medium intensity approach lighting system with sequenced flashers right of centerline, 8:1 slope to clearĪPCH RATIO 32:1 TO DSPLCD THR +43 FT LGTD POLE 1414 FT FM THR 75 FT R APCH RATIO 46:1.Ĥ-light PAPI on right (3.00 degrees glide path) +8 FT FENCE 200 FT FM THR & 400 FT R 40 FT LGT POLES PARL TO RWY BTN TWY Q & A-4 650 FT N.ģ3 ft. MALSR: 1,400 foot medium intensity approach lighting system with runway alignment indicator lightsġ4 ft. Runway Information Runway 10L/28R Dimensions:Īsphalt/concrete/grooved, in excellent conditionĤ-light PAPI on left (3.00 degrees glide path) Nearby radio navigation aids VOR radial/distance
